| Model | Unit | EOP3-2.7 | EOP3-3.3 | EOP3-4.0 | EOP3-4.5 |
|---|---|---|---|---|---|
| Max Platform height (H) | mm | 2700 | 3300 | 4000 | 4500 |
| Max Machine height (H1) | mm | 4120 | 5000 | 5400 | 6000 |
| Load capacity | kg | 300 | 300 | 300 | 300 |
| Platform size | mm | 600x640 | 600x640 | 600x640 | 600x640 |
| Max driving speed (Lowered) | km/h | 4 | 4 | 4 | 4 |
| Max driving speed (Raised) | km/h | 1.6 | 1.6 | 1.6 | 1.6 |
| Min turning radius | mm | 1600 | 1600 | 1600 | 1600 |
| Max climbing ability | % | 15~20 | 15~20 | 15~20 | 15~20 |
| Maintenance Free Battery | v/Ah | 2x12/150 | 2x12/150 | 2x12/150 | 2x12/150 |
| Overall size (AXBXC) | mm | 1530x700x1830 | 1530x700x2130 | 1620x700x1840 | 1620x700x2000 |
| Net weight | kg | 430 | 450 | 660 | 680 |
All models in this series have a standard load capacity of 300kg, making them ideal for small to medium-sized warehouse goods picking.
The platform heights range from 2700mm to 4500mm, depending on the specific model selected (EOP3-2.7 to EOP3-4.5).
The order picker is equipped with a maintenance-free battery (2x12V/150Ah) and comes with a 24V/15A charger for efficient operations.
When the platform is lowered, the maximum driving speed is 4 km/h. For safety, the speed is limited to 1.6 km/h when the platform is raised.
Yes, with a minimum turning radius of only 1600mm and a compact width of 700mm, it is specifically designed for small aisle warehouse operations.
The equipment is securely packed in a wooden box to ensure maximum protection during international transport.
